MikroTik: Setup a Site-to-Site OpenVPN Connection

In this example, we will be using two MikroTik RB951G-2HnD running RouterOS v6.34.3 on firmware v3.24, each using a different subnet. In addition, the OpenVPN tunnel is using a different subnet as well, which means – between the two MikroTik routers and the OpenVPN tunnel, we have three different subnets. The OpenVPN local and remote IP addresses represent the respective gateway address for each end of the tunnel between MikroTik A (Server) and MikroTik B (Client). These are static IP addresses. For example, MikroTik A’s OpenVPN gateway IP address is 192.168.200.254 and MikroTik B’s OpenVPN gateway IP address is 192.168.200.10. The OpenVPN local and remote IP addresses are configured in the PPP profile, which we will get to later.

We will need to create the certificates on MikroTik A (Server). For simplicity (I hope), I’ve added the MikroTik terminal commands needed to create the certificates. Note that these commands include placeholders that will need to be changed to better suit your network environment. The variables/placeholders are encapsulated by the percent (%) symbol. I’ve included the following list of placeholders, that will need to be changed:

  • %MikroTik Identity%
  • %Client Name%
  • %MikroTik Local IP%
  • %Passphrase%

MikroTik A (Server): Certificate Setup & Export

Create the Certificates

/certificate add name=ca-template common-name=CA-%MikroTik Identity% key-usage=key-cert-sign,crl-sign
/certificate add name=server-template common-name=SERVER
/certificate add name=client-%Client Name%-template common-name=client-%Client Name%

Sign the Certificates

/certificate sign ca-template ca-crl-host=%MikroTik Local IP% name=CA-%MikroTik Identity%
/certificate sign ca=CA-%MikroTik Identity% server-template name=SERVER
/certificate sign ca=CA-%MikroTik Identity% client-%Client Name%-template name=client-%Client Name%

Enable “trusted” for the Certificate Authority and Server Only

/certificate set CA-%MikroTik Identity% trusted=yes
/certificate set SERVER trusted=yes
The Certificates window should now look similar to this screenshot.

Export the Certificates

/certificate export-certificate CA-%MikroTik Identity%
/certificate export-certificate client-%Client Name% export-passphrase=%Passphrase%
The File List window should now contain the exported certificates.

Copy/Move the exported certificates from Mikrotik A (Server) to Mikrotik B (Client).

MikroTik B (Client): Certificate Setup & Import

Import the Certificates

/certificate import file-name=cert_export_CA-%MikroTik Identity%.crt passphrase=""
/certificate import file-name=cert_export_client-%Client Name%.crt passphrase=%Passphrase%
/certificate import file-name=cert_export_client-%Client Name%.key passphrase=%Passphrase%
The Certificates window should now look similar to this screenshot.

MikroTik A (SERVER): OpenVPN PPP Configuration

Import the Certificates

/ppp profile add name=openvpn local-address=192.168.200.254 remote-address=192.168.200.10 change-tcp-mss=yes use-compression=no use-encryption=required

OR Navigate to PPP > Profiles and create a new PPP Profile (modify settings as needed):

In the screenshot above, don’t forget to check the protocols tab. Under the protocols tab, the option for “Use Compression” and “Use Encryption” can be set. These two options are already set in the command, but cannot be seen in the screenshot. In addition, take note of the Local and Remote IP addresses (192.168.200.254 and 192.168.200.10), these two addresses define the static IP assigned to each end of the VPN tunnel. These IP addresses can be set to anything you want as long as they don’t match any of the existing subnets that are currently in use at each site.

Create a PPP Secret (modify command as needed)

/ppp secret add name=NewYork password=NyTx325 profile=openvpn service=ovpn

OR Navigate to PPP > Secrets and create a new PPP Secret (modify settings as needed):

Configure the OVPN Server (modify command as needed):

/interface ovpn-server server set certificate=SERVER cipher=blowfish128,aes128,aes192,aes256 default-profile=openvpn enabled=yes require-client-certificate=yes

OR Navigate to PPP > Interface, click on the OVPN Server button and configure the OVPN Server (modify settings as needed):

Create a Route (modify command as needed):

/ip route add dst-address=192.168.88.0/24 gateway=192.168.200.10

OR Navigate to IP > Routes and create a new Route (modify settings as needed):

MikroTik A (Server): OpenVPN Firewall/NAT Configuration

Create the Firewall Filter and NAT bypass rules (modify command as needed):

/ip firewall filter add chain=input dst-port=1194 protocol=tcp
/ip firewall nat add chain=srcnat src-address=192.168.100.0/24 dst-address=192.168.88.0/24 place-before=0

MikroTik B (Client): OpenVPN PPP Configuration

Create a OVPN Client (modify command as needed)

/interface ovpn-client add certificate=cert_export_client-NewYork.crt_0 cipher=aes256 connect-to=71.157.75.49 mac-address=02:2F:03:6C:10:59 name=ovpn-Texas password=NyTx325 profile=default-encryption user=NewYork

OR Navigate to PPP > Interface, create a new OVPN Client:

MikroTik B (Client): OpenVPN Routes Configuration

Create a Route (modify command as needed):

/ip route add dst-address=192.168.100.0/24 gateway=192.168.200.254

OR Navigate to IP > Routes and create a new Route (modify settings as needed):

MikroTik B (Client): OpenVPN Firewall/NAT Configuration

Create the Firewall Filter and NAT bypass rules (modify command as needed):

/ip firewall filter add chain=input dst-port=1194 protocol=tcp
/ip firewall nat add chain=srcnat src-address=192.168.88.0/24 dst-address=192.168.100.0/24 place-before=0

8 thoughts on “MikroTik: Setup a Site-to-Site OpenVPN Connection”

  1. Hi, very useful article, congratulations.
    192.168.88.0/24 is the local network from B SIDE?
    192.168.100.0/24 is the local network from A Site, correct?

  2. HI, how i can route all traffic from B (Client) to A(Server) ?
    So that the all traffic inclufing internet traffic gos through the tunnel…
    thx, Richard

    1. I haven’t set up a site-to-site VPN in this way yet, but I would not use OVPN for this and instead use GRE over IPSEC. Client site would need Mangle rules to mark traffic and route to Server site. Server site would need NAT/Masquerade rules and system in place to allow marked traffic out to the internet. When I have more time, I’ll see if I can create a virtual lab and test this out myself. I just don’t have a lot of time at the moment.
